2026-06-22

Standard test sieves adopt vertical vibration motors as the vibration source. The vibration motor drives the upper vibrating tray, which transfers vibration to the sieve frames placed on top of the tray. Material particles smaller than the mesh apertures pass through the target sieve frame into the layer below. Through this layered screening process, each test sieve retains materials of uniform particle size, realizing separation of particles with different sizes, determining the particle size composition of materials, and achieving effective filtration, grading and screening.Application IndustriesWidely used in R&D, production, laboratories, quality inspection departments and universities across metallurgy, chemical, pharmaceutical, powder, building materials, national defense, geology, petroleum, agriculture, food and other industries.Operation PrecautionsAdjust the operation time as required. The first two digits of the time relay represent minutes, and the last two represent seconds. Set the reading of the time relay to your desired duration.Place the test sieve frames inside the equipment and tighten the nuts before starting the machine.The test sieve shaker will shut down automatically once the running time reaches the preset value; take out the sieve frames carefully afterwards.

More >

2026-06-22

The XMD test sieve shaker is a particle size analysis instrument featuring timed automatic shutdown for consistent test repeatability and simple operation. It can precisely separate one type of granular material into 2 to 7 particle fractions simultaneously. It is also applicable to analyzing the fineness and impurity content of slurry materials. With low noise and light weight, it adopts tabletop operation and requires no fixation. Its vibration speed and amplitude are adjustable.It delivers high screening accuracy and efficiency in inspection procedures, capable of screening materials ranging from 0.025 mm to 3 mm.The cabinet and vibrating tray of the test sieve shaker are elaborately manufactured from SUS304 stainless steel, featuring corrosion resistance, high temperature resistance, rust-proof performance and non-magnetic property.Timed automatic shutdown function ensures repeatable test results.It can hold up to 8 layers of sieve frames, enabling simultaneous precise separation of one granular material into 2 to 8 particle fractions.

More >

2026-06-22

CNC test sieve shakers are widely used for inspection and analysis in research institutions, laboratories, testing rooms and production control departments across food, pharmaceutical, chemical, abrasive, pigment, mining, metallurgy, geology, ceramic, national defense and other industries.Food IndustrySugar, monosodium glutamate powder, salt, fruit juice, starch, milk powder, food raw materials, soybean milk, egg powder, rice flour, soy sauce, fish meal, pineapple juice, etc.Metallurgical IndustryCarbon black, fluxing agent, activated carbon, pearl powder, etc.Chemical IndustryResin, coating, medical raw materials, pharmaceuticals, cosmetics, fire extinguishing agent, plastic powder, abrasive glass, etc.Ceramic IndustryGrinding materials, alumina, ceramic slurry, clay slurry, glass powder, refractory materials, quartz sand, PVC resin particles, citric acid, polyethylene powder, laundry detergent, etc.

More >

2026-06-22

Stainless steel test sieving mesh is widely used for screening, filtration, protection and decoration, covering industries including mining, petroleum, chemical, food, pharmaceutical, machinery manufacturing, architectural decoration, electronics, aerospace and more.Now let Green Energy’s editor share the precautions for using stainless steel sieving mesh.Properly control the aperture size of stainless steel sieve plates and avoid improper tightening of bolts. Ensure the stainless steel sieve plates match the screening machine to reduce tension plate deformation and control the fitting degree between stainless steel sieve plates and tensioning parts; otherwise, the service life of the sieve plates will be greatly shortened. In addition, the amplitude of stainless steel sieve plates should be properly regulated.To guarantee stable working efficiency of stainless steel sieving mesh, operate it strictly in accordance with the manufacturer’s instructions in daily use so as to extend its service life.

More >

2026-06-22

Filter screens feature acid resistance, alkali resistance, temperature resistance, wear resistance and other properties. They are mainly applied in mining, petroleum, chemical, food, pharmaceutical, machinery manufacturing and other industries. Filter screens fall into two categories: textile fiber filter screens and metal filter screens. Equipment equipped with filter screens is called a filter, which is used to filter tap water, food materials and other substances.Wuxi Lvneng Precision Filter Equipment Co., Ltd. adheres to the business philosophy of "customer-oriented, based on low prices and high quality, targeting customer satisfaction". We win customers' trust with favorable prices and advanced technical equipment. We sincerely welcome customers from all walks of life and are ready to join hands with partners worldwide to create a brilliant future together!Now the editor from Lvneng will share the daily functions of filter screens.Filter screens are widely installed in air conditioners, air purifiers, range hoods, air filters, dehumidifiers, dust collectors and other equipment. They meet diverse requirements of filtration, dust removal and separation, and serve filtration procedures in petroleum, chemical, mining, food, pharmaceutical and various other industries. Filter screens are gaining increasingly extensive applications and are frequently used in ordinary households as well.

More >

2026-06-22

In the building materials industry, using vitrified microbeads as lightweight aggregate can improve the workability, fluidity and self-strength of mortar, lower material shrinkage rate, enhance the overall performance of finished products and cut comprehensive production costs. Different industrial applications require drastically different particle sizes of the material, so vitrified microbeads are classified into Grade 1, Grade 2, Grade 3 and other grades based on particle size. A complete vitrified microbead production line consists of crushers, screening machines, conveyors and other major equipment. After vitrified microbeads are crushed to below 10 mm, fine screening equipment is required for grading. Common mesh sizes for grading vitrified microbeads include 20 mesh, 50 mesh, 70 mesh, 90 mesh, 120 mesh and 180 mesh. The grading accuracy must be controlled within ±10%, which sets high standards for the precision of vibrating screening equipment.

More >

2026-06-22

Wet materials have poor fluidity and tend to clog mesh screens, resulting in unsatisfactory screening results, which has long been a troublesome problem for customers. Some people try tapping the screen manually, yet the effect remains unsatisfactory. Different types of wet materials processed by sieve shakers lead to varying degrees of mesh clogging. Here are several practical tips to help users select proper solutions to resolve clogging issues:Increase the exciting force of the vibration motor to raise the frequency of three-dimensional movement of materials on the screen surface.Adopt wet screening: add water to dilute materials and improve their fluidity.

More >

2026-06-22

Recently, many users have consulted me and asked, "Can tapping test sieves be used for material testing in laboratories?" Today I will give a unified answer in this article: Yes.The tapping test sieve is a commonly used small tapping vibrating sieve machine. It serves as a testing and analysis sieve for coal quality testing, as well as experimental and analytical work in geology, metallurgy, chemical industry, scientific research, cement and many other industrial sectors. It can be regarded as screening equipment specially designed for laboratory use.So what are the advantages of tapping test sieves as dedicated laboratory screening equipment?Three Major Advantages of Tapping Test SievesMature structure, long service life and low maintenance costThe two gears of the tapping sieve are not in direct contact, resulting in slight wear. The synchronous belt and gears feature good adaptability, delivering a longer service life; only the synchronous belt needs to be replaced during maintenance. Meanwhile, the eccentric wheel assembly adopts an integrated structure for accurate and convenient reinstallation. Standard bearings are used for rotating parts, which are resistant to wear, easy to replace and low-cost, greatly reducing maintenance difficulty and expenses.Fast transmission with timing functionThe transmission mode driven by gears and synchronous belts provides an accurate speed ratio without speed loss, enabling high screening efficiency. Its unique design allows the tapping sieve to generate both reciprocating motion and tapping vibration during operation, effectively preventing mesh clogging. It features fast material discharge, thorough screening and high efficiency. In addition, the tapping sieve is equipped with a timing function to guarantee consistent test results. The power controller supports preset working time and automatic shutdown, ensuring uniform test data for production batches.Low energy consumption, clean and hygienicThe unique transmission structure adopted by the new-type tapping sieve cuts maintenance costs and effectively protects the working environment, meeting users' requirements for cleanliness.

More >

2026-06-22

Stainless steel sample sieves are widely used in scientific research, production, laboratories, quality inspection rooms of abrasives, geological exploration, metallurgy, pharmacopoeia testing, chemical industry, pharmaceuticals, powder materials, building materials, national defense, geology and other sectors, as well as laboratories of institutions of higher learning. They are used for accurate screening, filtration and detection of granular and powdery materials in terms of particle size composition, solid content in liquids and impurity content.Xianchen test sieves adopt a new special power generator to generate multi-dimensional high-frequency vibration for efficient sample screening and filtration. The standard sieve body ensures high precision of sample analysis. Equipped with an electronic timer, it can set consistent screening duration for the same type of materials as required, guarantee uniform sample analysis data and reduce inspection errors, so as to make accurate judgments on product quality.

More >

2026-06-22

Wet materials have poor fluidity and are prone to screen clogging, leading to unsatisfactory screening results, which has long been a vexing problem for customers. Some operators tap the screen manually, yet the effect is still poor. The degree of clogging varies depending on the type of wet material being processed by the sieve shaker. Below are several practical tips to help users adopt proper solutions for mesh clogging:Increase the exciting force of the vibration motor to raise the frequency of three-dimensional motion of materials on the screen surface.Adopt wet screening: dilute materials with water to improve their fluidity.

More >
